Implements the ByteTree virtual class in the case when the data stored is not other bytetrees but actual bytes. More...

#include <leaf.hpp>

Inheritance diagram for verifierUtils::Leaf:

Collaboration diagram for verifierUtils::Leaf:

Public Member Functions
	Leaf (std::vector< uint8_t > content)
	Initializes the bytes attribute of a new Leaf instance directly.
	Leaf (std::string &s)
	Reads a leaf from a string containing a byte representation and removes the data read from it.
	Leaf (mpz_class number)
	Turns a number into the Leaf of a ByteTree.
	Leaf (mpz_class number, unsigned int size)
	Turns a number into the Leaf of a ByteTree with a fixed number of bytes.
	~Leaf ()
	Empties the content of bytes during destruction.
std::string	toString ()
	Turns this object into a string.
std::vector< uint8_t >	toVector ()
	Turns this object into a vector of bytes.
mpz_class	toNumber ()
std::vector< bool >	toBoolArray ()
	Turns this object into a vector of boolean.
bool	isNode ()
	To know if the instance used is a Node.
bool	isLeaf ()
	To know if the instance used is a Leaf.
mpz_class	toInteger ()
	Turns this object into an arbitrarily large integer.
unsigned int	size ()
	The number of bytes in a Leaf and the number of ByteTrees in a Node.
void	prettyPrint (std::string indent)
	Recursively prints an indented version of the ByteTree (mainly for debugging)
bool	compare (std::string s)
	Compare the bytes contained in this leaf with those in the input.
Public Member Functions inherited from verifierUtils::ByteTree
	ByteTree ()
	Empty constructor to please the compiler.
	~ByteTree ()
	Empty destructor to please the compiler.
virtual void	addChild (ByteTree *bt)
	Adds the ByteTree given in the argument to the children attribute in a Node; exits with exit code 1 if the ByteTree is a Leaf.
virtual ByteTree *	getChild (unsigned int i)
	Returns the child of index i if we have a Node; exits with exit code 1 if the ByteTree is a Leaf.

Private Attributes
std::vector< uint8_t >	bytes
	The actual bytes stored in this leaf.

Additional Inherited Members
Static Public Member Functions inherited from verifierUtils::ByteTree
static ByteTree *	parseString (std::string &s)
	Parses a string by constructing a ByteTree of the correct kind.
static ByteTree *	parseVector (std::vector< uint8_t > &v)
	Parses a vector of bytes by constructing a ByteTree of the correct kind; returns Leaf(0) if the vector is empty.
static ByteTree *	parseFile (std::string path)
	Parses a file containing the string representation of a bytetree and returns the said bytetree. If the file does not exist, returns NULL.
static ByteTree *	string2ByteTree (std::string s)
	Turns a string into its ByteTree representation. Not to be mistaken with parseString!

Detailed Description

Implements the ByteTree virtual class in the case when the data stored is not other bytetrees but actual bytes.

See the verificatum verifier documentation (page 5) for more details on how this is supposed to work.

See Also: btrtest.cpp

Definition at line 28 of file leaf.hpp.

Constructor & Destructor Documentation

Leaf::Leaf ( std::vector< uint8_t > content )

Initializes the bytes attribute of a new Leaf instance directly.

Parameters

content The bytes this Leaf must contain.

Definition at line 23 of file leaf.cpp.

{
        bytes = content;
}

Leaf::Leaf ( std::string & s )

Reads a leaf from a string containing a byte representation and removes the data read from it.

For s="010000000201010000000001AA", creates a leaf containing two bytes equal to 1 and, at the end of the call, s="010000000001AA". It is assumed that the string is a correctly formatted Leaf. No verifications are made!

Parameters

[in,out] s The string to parse. It must start with "01".

Definition at line 46 of file leaf.cpp.

{
        if ((s.compare(0,2,"01") != 0) || (s.size()%2 !=0))
        {
                std::cout<<"ERROR: in Leaf(string), input does not "
                        "start with '01' or has an odd length"
                         <<std::endl<<"input: '"<<s<<"'"<<std::endl;
                exit(1);
        }
        else
        {
                // reading number of bytes
                unsigned int l = octuple2num(s.substr(2,8));
                if ((10+l*2) > s.size())
                {
                        std::cout<<"ERROR in Leaf::Leaf(string): the "
                                "input is too small! Input: "<<s
                                 <<std::endl;
                        exit(1);
                }
                else
                {
                        bytes.resize(l);
                        // reading actual bytes
                        for (unsigned int i=0; i < l; i++)
                                bytes[i] = doublon2byte(s[10+i*2],
                                                        s[11+i*2]);
                        // cutting what we just read from the string
                        s = s.substr(10+l*2,std::string::npos);
                }
        }
}

Leaf::Leaf ( mpz_class number )

Turns a number into the Leaf of a ByteTree.

Parameters

number The number to store in this leaf

Definition at line 29 of file leaf.cpp.

{
        bytes = largeNum2byteVector(number);
}

Leaf::Leaf	(	mpz_class	number,
		unsigned int	size
	)

Turns a number into the Leaf of a ByteTree with a fixed number of bytes.

Parameters

number	The number to store in this leaf.
size	The number of bytes which will actually be stored.

Definition at line 35 of file leaf.cpp.

{
        bytes.resize(size);
        for (int i = bytes.size()-1; i>=0; i--)
        {
                bytes[i] = number.get_ui() % 0x100;
                number = number / 0x100;
        }
}

Leaf::~Leaf ( )

Empties the content of bytes during destruction.

Definition at line 80 of file leaf.cpp.

{
        bytes.clear();
}

Member Function Documentation

bool Leaf::compare ( std::string s )

virtual

Compare the bytes contained in this leaf with those in the input.

Functions (almost) like std::string.compare(): outputs false if the bytes in the leaf correspond to the string given in the input, true otherwise. For instance, Leaf(65,66,67).compare("ABC") == false.

Parameters

s	The string to compare.

Returns: False if the string and the bytes are identical, true otherwise. In particular, always return true if we don't have a Leaf.

Reimplemented from verifierUtils::ByteTree.

Definition at line 156 of file leaf.cpp.

{
        bool different = (s.size() != bytes.size());
        if (different)
                return true;
        else
        {
                for (unsigned int i=0; i < s.size(); i++)
                        if ((uint8_t)s[i] != bytes[i])
                        {
                                different = true;
                                break;
                        }
                return different;
        }
}

bool Leaf::isLeaf ( )

virtual

To know if the instance used is a Leaf.

Returns: true if the type of this object is an instance of the class Leaf, false otherwise.

Reimplemented from verifierUtils::ByteTree.

Definition at line 117 of file leaf.cpp.

{
        return true;
}

bool Leaf::isNode ( )

virtual

To know if the instance used is a Node.

Returns: true if the type of this object is an instance of the class Node, false otherwise.

Reimplemented from verifierUtils::ByteTree.

Definition at line 111 of file leaf.cpp.

{
        return false;
}

void Leaf::prettyPrint ( std::string indent )

virtual

Recursively prints an indented version of the ByteTree (mainly for debugging)

Parameters

indent The characters to be printed in the indentation.

Reimplemented from verifierUtils::ByteTree.

Definition at line 147 of file leaf.cpp.

{
        std::cout<<indent;
        for (unsigned int i=0; i<bytes.size(); i++)
                std::cout<<verifierUtils::byte2str(bytes[i]);
        std::cout<<std::endl;
}

unsigned int Leaf::size ( )

virtual

The number of bytes in a Leaf and the number of ByteTrees in a Node.

Returns: The size of this instance.

Reimplemented from verifierUtils::ByteTree.

Definition at line 141 of file leaf.cpp.

{
        return bytes.size();
}

std::vector< bool > Leaf::toBoolArray ( )

virtual

Turns this object into a vector of boolean.

Returns: The boolean stored in the bytes if it is a Leaf, exits with exit code 1 otherwise.

Reimplemented from verifierUtils::ByteTree.

Definition at line 132 of file leaf.cpp.

{
        std::vector<bool> result(bytes.size());
        for (unsigned int i=0; i<bytes.size(); i++)
                result[i] = (bytes[i] == 1);
        return result;
}

mpz_class Leaf::toInteger ( )

virtual

Turns this object into an arbitrarily large integer.

Returns: The integer stored in the bytes if it is a Leaf; 0 otherwise.

Reimplemented from verifierUtils::ByteTree.

Definition at line 123 of file leaf.cpp.

{
        mpz_class result = 0;
        for (unsigned int i=0; i<bytes.size(); i++)
                result = (result * 0x100) + bytes[i];
        return result;
}

mpz_class verifierUtils::Leaf::toNumber ( )

std::string Leaf::toString ( )

virtual

Turns this object into a string.

Returns: The string representation of this instance.

Reimplemented from verifierUtils::ByteTree.

Definition at line 86 of file leaf.cpp.

{
        std::string result;
        std::vector<uint8_t> byteRepresentation = toVector();
        for (unsigned int i=0; i<byteRepresentation.size(); i++)
                result += byte2str(byteRepresentation[i]);
        return result;
}

std::vector< uint8_t > Leaf::toVector ( )

virtual

Turns this object into a vector of bytes.

This aim is to allow an easy hashing of the ByteTree's.

Returns: The byte representation of the ByteTree.

Reimplemented from verifierUtils::ByteTree.

Definition at line 96 of file leaf.cpp.

{
        std::vector<uint8_t> result;
        result.push_back(1); // Node starts with a 0x01 byte
        // Adding the number of bytes
        uint32_t byteNumber = bytes.size();
        result.push_back((byteNumber>>24) % 0x100);
        result.push_back((byteNumber>>16) % 0x100);
        result.push_back((byteNumber>> 8) % 0x100);
        result.push_back( byteNumber      % 0x100);
        // Adding the bytes contained in the leaf
        result.insert(result.end(),bytes.begin(), bytes.end());
        return result;
}

Member Data Documentation

std::vector<uint8_t> verifierUtils::Leaf::bytes

private

The actual bytes stored in this leaf.

Definition at line 34 of file leaf.hpp.

The documentation for this class was generated from the following files:

verifierutils/bytetree/leaf.hpp
verifierutils/bytetree/leaf.cpp
